The Second Generation

The Tommy Gate G2 Series is a dual-cylinder, parallel-arm design which utilizes a pair of hydraulic cylinders to lower and raise the lift by applying direct power to both sides of the platform. With forty-two inches of vertical travel, the G2 Series is a great fit for most any service body.

Liftgate Capacity
Liftgate Capacity Icon

1300 & 1600lbs.

Hydraulic System
Hydraulic System Icon

Dual-Cylinder

Lift Style
Lift Style Icon

Parallel-Arm

G2 Series Features

  • Dual hydraulic cylinders
  • Virtually maintenance-free components
  • Recessed control
  • Larger platforms
  • Fully-enclosed hydraulic system located within the liftgate mainframe
G2 Series Overview Image A G2 Series Overview Image B
Full-enclosed hydraulic system. Image
Full-enclosed hydraulic system.

Hydraulic cylinders are built in-house. Precision cylinder welds are executed by robotic machines, while assembly and testing are done by hand.

Painted before assembled. Image
Painted before assembled.

Dual-drive liftgates provide increased durability for rigorous cycling and have low maintenance requirements. A paint-before-assembly process increases the longevity of the lift’s aesthetics.

  Models for Service Bodies w/ 48" Openings

Model Capacity Load Area Taper Travel Weight Applications Spec
G2-54-1342 TP27 1300 49  x  27 4 42 415 A
G2-54-1342 TP38 1300 49  x  38 4 42 453 A
G2-54-1342 TP42 1300 49  x  42 7 42 477 A
G2-54-1342 TT27 1300 50  x  27 4 42 416 A
G2-54-1342 EA27 1300 49  x  27 6 42 375 A
G2-54-1342 EA38 1300 49  x  38 6 42 399 A
G2-54-1342 EA48 1300 49  x  48 6 42 419 A
G2-54-1342 BG27 1300 50  x  28 4 42 422 A
G2-54-1642 TP27 1600 49  x  27 4 42 415 A
G2-54-1642 TP38 1600 49  x  38 4 42 453 A
G2-54-1642 TP42 1600 49  x  42 7 42 477 A
G2-54-1642 TT27 1600 50  x  27 4 42 416 A
G2-54-1642 EA27 1600 49  x  27 6 42 375 A
G2-54-1642 EA38 1600 49  x  38 6 42 399 A
G2-54-1642 EA48 1600 49  x  48 6 42 419 A
G2-54-1642 BG27 1600 50  x  27 4 42 422 A

= Guaranteed Stock Model. Learn More.

  1. EA48 platform extends 10" above liftgate mainframe when closed.
  2. Please provide bed height and body opening measurements when ordering.

  Models for Service Bodies w/ 54" Openings

Model Capacity Load Area Taper Travel Weight Applications Spec
G2-60SB-1342 TP27 1300 55  x  27 4 42 450 B
G2-60SB-1342 TP38 1300 55  x  38 4 42 500 B
G2-60SB-1342 TP42 1300 55  x  42 7 42 525 B
G2-60SB-1342 TT27 1300 56  x  27 4 42 445 B
G2-60SB-1342 EA27 1300 55  x  27 6 42 430 B
G2-60SB-1342 EA38 1300 55  x  38 6 42 455 B
G2-60SB-1342 EA48 1300 55  x  48 6 42 485 B
G2-60SB-1342 BG27 1300 56  x  28 4 42 460 B
G2-60SB-1642 TP27 1600 55  x  27 4 42 450 B
G2-60SB-1642 TP38 1600 55  x  38 4 42 500 B
G2-60SB-1642 TP42 1600 55  x  42 7 42 525 B
G2-60SB-1642 TT27 1600 56  x  27 4 42 445 B
G2-60SB-1642 EA27 1600 55  x  27 6 42 430 B
G2-60SB-1642 EA38 1600 55  x  38 6 42 455 B
G2-60SB-1642 EA48 1600 55  x  48 6 42 485 B
G2-60SB-1642 BG27 1600 56  x  28 4 42 460 B

= Guaranteed Stock Model. Learn More.

  1. EA48 platform extends 10" above liftgate mainframe when closed.
  2. Please provide bed height and body opening measurements when ordering.

...

  Additional Models

Model Capacity Load Area Taper Travel Weight Applications Spec
G2-65-1350 TP35 1300 61  x  35 6 50 520 F
G2-65-1350 TP41 1300 61  x  41 6 50 541 F
G2-65-1350 TT33 1300 61  x  33 6 50 508 F
G2-65-1350 EA37 1300 60  x  37 6 50 471 F
G2-65-1350 EA41 1300 60  x  41 6 50 482 F
G2-65-1350 BG33 1300 62  x  33 6 50 527 F
G2-65-1650 TP35 1600 61  x  35 6 50 520 F
G2-65-1650 TP41 1600 61  x  41 6 50 541 F
G2-65-1650 EA41 1600 60  x  41 6 50 482 F
G2-65-1650 BG33 1600 62  x  33 6 50 527 F
G2-65-1650 EA37 1600 60  x  37 6 50 471 F
G2-65-1650 TT33 1600 61  x  33 6 50 508 F

= Guaranteed Stock Model. Learn More.

Show Additional Models

  Applications & Brackets - Service Body → G2 Series

Code Body Style
B Service / Utility Body w/ 54" Opening
A Service / Utility Body w/ 48" Opening

 Available Platforms

TP27

1-piece treadplate steel w/ 27" loading depth + 4" taper

G2 Series TP27 Open G2 Series TP27 Closed
TP38

2-piece treadplate steel w/ 38" loading depth + 4" taper

G2 Series TP38 Open G2 Series TP38 Closed
TP42

2-piece treadplate steel w/ 42" loading depth + 7" taper

G2 Series TP42 Open G2 Series TP42 Closed
TT27

1-piece TommyTraction steel w/ 27" loading depth + 4" taper

G2 Series TT27 Open G2 Series TT27 Closed
EA27

1-piece extruded aluminum w/ 27" loading depth + 6" taper

G2 Series EA27 Open G2 Series EA27 Closed
EA38

2-piece extruded aluminum w/ 38" loading depth + 6" taper

G2 Series EA38 Open G2 Series EA38 Closed
EA48

2-piece extruded aluminum w/ 48" loading depth + 6" taper

G2 Series EA48 Open G2 Series EA48 Closed
BG27

1-piece bargrate steel w/ 27" loading depth + 4" taper

G2 Series BG27 Open G2 Series BG27 Closed

  Standard Features

Fixed & Timed Toggle Control Image
Fixed & Timed Toggle Control

prevents unauthorized use, and deactivates 90 seconds after operation

Power Cable w/ Full Length Ground Image
Power Cable w/ Full Length Ground

ensures consistent power supply

150-amp Circuit Breaker Image
150-amp Circuit Breaker

protects vehicle's electrical system, disconnects power for repairs

Maintenance-free Pins and Bushings Image
Maintenance-free Pins and Bushings

ensure consistent platform operation, require zero maintenance

  Available Options

Bolt-on LED 3-Light Kit T-57L Image
Bolt-on LED 3-Light Kit T-57L

Kit includes a pair of 3-light, LED combined stop/turn function lights (12v/24v compatible)

Bolt-on LED 3-Light Kit T-58L Image
Bolt-on LED 3-Light Kit T-58L

Kit includes a pair of 3-light, LED combined stop/turn function lights (12v compatible)

Bolt-on 2-light LED Light Kit T-67L Image
Bolt-on 2-light LED Light Kit T-67L

Kit includes a pair of 2-light, LED combined stop/turn function (one red, one white) lights (12v compatible)

Remote Pendant Control Image
Remote Pendant Control

allows additional operator movement

Dual Controls Image
Dual Controls

standard fixed control + remote pendant control

Rubber Platform Bumpers Image
Rubber Platform Bumpers

protects platform from scratching (sets of four or six)

Folding Tire Rack Image
Folding Tire Rack

provides support and stability for tire handlers

Extra Bracket Kit Image
Extra Bracket Kit

top bracket and gussets only (one set included with liftgate)

Galvanizing Option Image
Galvanizing Option

metallic-zinc coating prevents corrosion from harmful environmental elements

In-cab, Shut-off Switch Image
In-cab, Shut-off Switch

enables power to be disabled from within the truck cab

G2 Series Gas Bottle Bracket Image
G2 Series Gas Bottle Bracket

This optional kit allows liftgate operators to secure one gas bottle on any G2 Series liftgate.

CS Component Kit Image
CS Component Kit

repositions the rear camera (C) and sensors (S) while retaining functionality

1. Galvanizing option may increase production time and is not available for Treadplate Steel platforms.

Documents

  G2 Series

Document Name Size Download
G2 Series Owner's Manual 1549kb
Pickup & Service Body - G2 Series Parts List 222kb
Service Body - G2 Series Dimensions 236kb
Estimated Installation Times 452kb
G2 Series - Gas Bottle Bracket Flyer 620kb
G2-Series Galvanizing Option 229kb
Service Body Installation Instructions 3487kb
Electrical Guidelines 14kb
G2 Series Wiring Instructions 72kb
G2 Series Cylinder Repair Instructions 1942kb
G2 Series Latch Replacement/Adjustment 199kb
G2 Series EA Platform and Torsion Replacement 236kb
Torsion Spring / Extension Installation 44kb
Folding Tire Rack Instructions 490kb
T-67 Bolt-on Light Kit Mounting Instructions 1120kb
T-57/ T-58 Bolt-on Light Kit Instructions 1120kb
Tommy Gate Liftgate Guide 9133kb
